Suzuki GSF650 Service Manual

5C-1 Clutch:
Transmission / Transaxle
Clutch
Precautions
Precautions for Clutch System
B817H25300001
Refer to “General Precautions in Section 00 (Page 00-1)”.
Clutch Fluid (Brake Fluid) Information
B817H25300002
WARNING
!
• This clutch system is filled with an ethylene glycol-based DOT 4 brake fluid. Do not use or mix
different types of fluid such as silicone-based or petroleum-based.
• Do not use any brake fluid taken from old, used or unsealed containers. Never reuse brake fluid left
over from the last servicing or stored for long periods.
• When storing brake fluid, seal the container completely and keep away from children.
• When replenishing brake fluid, take care not to get dust into fluid.
• When washing clutch components, use fresh brake fluid. Never use cleaning solvent.
CAUTION
!
Immediately and completely wipe off any brake fluid contacting any part of the motorcycle. The brake
fluid reacts chemically with paint, plastics and rubber materials, etc., and will damage them severely.

Suzuki GSF650 Specifications

General

Displacement	656 cc
Bore x Stroke	65.5 mm x 48.7 mm
Compression Ratio	11.5:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Starter	Electric
Transmission	6-speed, constant mesh
Final Drive	Chain
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Front Tire	120/70ZR17M/C (58W), tubeless
Rear Tire	160/60ZR17M/C (69W), tubeless
Overall Length	2, 130 mm
Rear Brakes	Disc brake
Fuel Tank Capacity	19.0 L
Wheelbase	1, 470 mm
Seat Height	790 mm
Ground Clearance	135 mm
Engine Type	4-stroke, liquid-cooled, DOHC, 4-cylinder
