Front Suspension: 2B-11
Special Tool
B817H22208002
09940–34520 09940–34531
T handle Attachment A
)(Page 2B-4) / )(Page 2B-
7)
)(Page 2B-4) / )(Page 2B-
7)
09940–52861 09943–74111
Front fork oil seal installer Fork oil level gauge
)(Page 2B-6) )(Page 2B-8)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Suzuki GSF650 and is the answer not in the manual?

Suzuki GSF650 Specifications

General IconGeneral
Displacement656 cc
Bore x Stroke65.5 mm x 48.7 mm
Compression Ratio11.5:1
Fuel SystemFuel injection
IgnitionElectronic ignition (transistorized)
StarterElectric
Transmission6-speed, constant mesh
Final DriveChain
Front SuspensionTelescopic, coil spring, oil damped
Rear SuspensionLink type, coil spring, oil damped
Front Tire120/70ZR17M/C (58W), tubeless
Rear Tire160/60ZR17M/C (69W), tubeless
Overall Length2, 130 mm
Rear BrakesDisc brake
Fuel Tank Capacity19.0 L
Wheelbase1, 470 mm
Seat Height790 mm
Ground Clearance135 mm
Engine Type4-stroke, liquid-cooled, DOHC, 4-cylinder
