1-4 GENERAL INFORMATION
SUZUKI VZ800K5 (’05-MODEL)
RIGHT SIDE LEFT SIDE
* Difference between illustration and actual motorcycle may exist depending on the markets.
SERIAL NUMBER LOCATION
The frame serial number or V.I.N. (Vehicle Identification Number) 1 is stamped on the right side of the
steering head pipe. The engine serial number 2 is located on the right side of the crankcase. These num-
bers are required especially for registering the machine and ordering spare parts.
FUEL, OIL AND ENGINE COOLANT RECOMMENDATION
FUEL (FOR USA AND CANADA)
Use only unleaded gasoline of at least 87 pump octane (R/2 + M/2) or 91 octane or higher rated by the
research method.
Gasoline containing MTBE (Methyl Tertiary Butyl Ether), less than 10% ethanol, or less than 5% methanol
with appropriate cosolvents and corrosion inhibitor is permissible.
FUEL (FOR OTHER COUNTRIES)
Gasoline used should be graded 91 octane (Research Method) or higher. Unleaded gasoline is recom-
mended.
SAMPLE

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Suzuki Intruder VZ800 and is the answer not in the manual?

Suzuki Intruder VZ800 Specifications

General IconGeneral
Engine Type4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement805 cc
Bore x Stroke83.0 mm x 74.4 mm
Compression Ratio9.4:1
Fuel SystemFuel injection
IgnitionElectronic ignition (transistorized)
Transmission5-speed constant mesh
Final DriveShaft drive
Front SuspensionTelescopic, coil spring, oil damped
Rear SuspensionLink type, coil spring, oil damped
Rear BrakeDrum brake
Seat Height700 mm (27.6 in)
Front BrakeDisc brake
Rear Tire170/80-15M/C 77H, tube type
Fuel Tank Capacity15.5 L (4.1 US gallons)
