Suzuki Intruder VZ800 User Manual

2-24 PERIODIC MAINTENANCE
FRONT FORK
Inspect the front forks for oil leakage, scoring or scratches on
the outer surface of the inner tubes. Replace any defective
parts, if necessary. (8-13)
REAR SUSPENSION
Inspect the damper for oil leakage and the spring unit for dam-
age. Check that there is no play in the swingarm assembly.
Replace any defective parts, if necessary. (8-40)
EXHAUST PIPE BOLT
• Tighten the exhaust pipe bolts and muffler mounting bolts to the specified torque.
 Muffler mounting bolt and exhaust pipe bolt A: 23 N·m (2.3 kgf-m, 16.5 lb-ft)
Muffler mounting nut B: 23 N·m (2.3 kgf-m, 16.5 lb-ft)
99000-32050: THREAD LOCK ‘‘1342’’
EXHAUST GAS SEALER: PERMATEX 1372

Inspect every 12 000 km (7 500 miles, 24 months).
Inspect every 12 000 km (7 500 miles, 24 months).
Tighten initially at 1 000 km (600 miles, 2 months) and
every 12 000 km (7 500 miles, 24 months) thereafter.
ITEM N·m kgf-m lb-ft
A 23 2.3 16.5
B 23 2.3 16.5
Apply PERMATEX 1372.
5 mm
(0.2 in)
5 mm
(0.2 in)
SAMPLE

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
