CHASSIS 8-67
VALVE INSPECTION
Inspect the valve after the tire is removed from the rim. Replace
the valve with a new one if the seal A rubber is peeling or has
damage.
NOTE:
If the external appearance of the valve shows no abnormal con-
dition, removing of the valve is not necessary.
If the seal has abnormal deformation, replace the valve with a
new one.
Any dust or rust around the valve hole B must be cleaned off.
Then install the valve C in the rim.
NOTE:
To properly install the valve into the valve hole, apply a special
tire lubricant or neutral soapy liquid to the valve.

Be careful not to damage the lip C of valve.
SAMPLE

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
