10-50 SERVICING INFORMATION
WATTAGE Unit: W
BRAKE + WHEEL Unit: mm (in)
ITEM
SPECIFICATION
E-03, 28, 33 E-24 Others
Headlight HI 60 ←←
LO 55 ←←
Position/Parking light 5
Brake light/Taillight LED ←←
Turn signal light 21/5 (Front),
21 (Rear)
21 ←
Licence plate light 5 ←←
Speedometer light LED ←←
Engine coolant temp. warning light LED ←←
Turn signal indicator light LED ←←
High beam indicator light LED ←←
Neutral indicator light LED ←←
Oil pressure indicator light LED ←←
FI indicator light LED ←←
ITEM STANDARD LIMIT
Rear brake pedal free travel 20 – 30
(0.8 – 1.2)
----
Rear brake pedal height 75 – 85
(3.0 – 3.3)
----
Brake drum I.D.
Rear ----
180.7
(7.11)
Brake disc thickness
Front
4.8 – 5.2
(0.19 – 0.21)
4.5
(0.18)
Brake disc runout
----
0.30
(0.012)
Master cylinder bore
Front
12.700 – 12.743
(0.5000 – 0.5017)
----
Master cylinder piston diam.
Front
12.657 – 12.684
(0.4983 – 0.4993)
----
Brake caliper cylinder bore
Front
30.230 – 30.306
(1.1901 – 1.1931)
----
Brake caliper piston diam.
Front
30.150 – 30.200
(1.1870 – 1.1889)
----
Wheel rim runout
Axial ----
2.0
(0.08)
Radial ----
2.0
(0.08)
Wheel axle runout
Front ----
0.25
(0.010)
Rear ----
0.25
(0.010)
Wheel rim size Front J16 M/C × MT 3.00 ----
Rear J15 M/C × MT 4.00 ----
SAMPLE

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
