PERIODIC MAINTENANCE 2-19
FINAL GEAR OIL
• Keep the motorcycle upright.
• Place an oil pan under the final gear case.
• Remove the filler cap 1 and drain plug 2 to drain oil.
• Refit the drain plug 2. Pour the specified oil (SAE 90 hypoid
gear oil with GL-5 under API classification) through the filler
hole until the oil level reaches the filler hole.
• Refit the filler cap 1.
Final gear oil: 200 – 220 ml
(6.8/7.0 – 7.4/7.7 US/Imp oz)
BRAKE
FRONT BRAKE FLUID LEVEL CHECK
• Keep the motorcycle upright and place the handlebars
straight.
• Check the brake fluid level by observing the lower limit line on
the front brake fluid reservoir.
• When the level is below the lower limit line, replenish with
brake fluid that meets the following specification.
Specification and classification: DOT 4
Replace initially at 1 000 km (600 miles, 2 months) and
inspect every 12 000 km (7 500 miles, 24 months)
thereafter.
(BRAKE)
Inspect initially at 1 000 km (600 miles, 2 months) and
every 6 000 km (4 000 miles, 12 months) thereafter.
(BRAKE HOSE AND BRAKE FLUID)
Inspect every 6 000 km (4 000 miles, 12 months).
Replace hoses every 4 years. Replace fluid every 2
years.
* The brake system of this motorcycle is filled with a
glycol-based brake fluid. Do not use or mix different
types of fluid such as silicone-based or petro-
leum-based. Do not use any brake fluid taken from
old, used or unsealed containers. Never re-use brake
fluid left over from the last servicing or stored for a
long period.
* Brake fluid, if it leaks, will interfere with safe running
and immediately discolor painted surfaces. Check
the brake hoses and hose joints for cracks and oil
leakage before riding.
