CHASSIS 8-69
• In this condition, check the “rim line” B cast on the tire side
walls. The line must be equidistant from the wheel rim all
around. If the distance between the rim line and wheel rim
varies, this indicates that the bead is not properly seated. If
this is the case, deflate the tire completely and unseat the
bead for both sides. Coat the bead with lubricant and fit the
tire again.
• When the bead has been fitted properly, adjust the pressure
to specification.
• As necessary, adjust the tire balance.

 Cold inflation tire pressure
BALANCER WEIGHT INSTALLATION
• When installing the balancer weights to the wheel, set the two
balancer weights A on both sides of wheel rim.

Do not run with a repaired tire at a high speed.
Front Rear
Solo riding
200 kPa
(2.00 kgf/cm², 29 psi)
250 kPa
(2.50 kgf/cm², 36 psi)
Dual riding
200 kPa
(2.00 kgf/cm², 29psi)
250 kPa
(2.50 kgf/cm², 36 psi)
Weight difference between the two balancer weights
must be less than 10 g (0.02 lb).
SAMPLE

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
