Suzuki Intruder VZ800 User Manual

5-14 FI SYSTEM
FI SYSTEM WIRING DIAGRAM
Intake air pressure sensor (IAPS) Front Intake air pressure sensor (IAPS) Rear
Engine coolant temperature sensor (ECTS) Intake air temperature sensor (IATS)
Tip-over sensor (TOS)
ECM
Heated oxygen sensor (HO2S)
Fuel pump
Fuel injector (FI)
#1 #2
Ignition coil (IG COIL) PAIR control solenoid valve
Secondary throttle position sensor (STPS)
Clutch lever position switch
Starter motor
Starter relay
10 A 10 A 30 A 15 A
Side-stand switch
Side-stand relay
Engine stop switch
Starter switch
Fuel pump relay
Ignition switch
Neutral indicator light
Gear position switch
N
51
4
3
2
Crankshaft position sensor (CKPS)
Throttle position sensor (TPS)
Secondary throttle valve actuator (STVA)
#1 #2
Speedometer
R/Bl
Gr/B
Gr/W
Y/B
Y
O/Y
O/G (E-02, 19, 24) O/W (E-03, 28, 33)
W
B/Y
Br/B
Bl
P
Y/G
Y/B B/W
B/W B/W
P/W
B/Lg
B
G
B/G
G/Y
Br
R
Bl/B
G/B
G/W
B/Bl
Dg
B/Br
Br/W
O/G (E-02, 19, 24) O/W (E-03, 28, 33)
W/B
W/Bl
B/Br
Y/W
R
B/Br
SAMPLE

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
