Suzuki Intruder VZ800 User Manual

SERVICING INFORMATION 10-41
CHASSIS
ITEM
N·m kgf-m lb-ft
Front axle 65 6.5 47.0
Front axle pinch bolt 23 2.3 16.5
Brake disc bolt 23 2.3 16.5
Front fork cap bolt 23 2.3 16.5
Front fork spring stopper nut 35 3.5 25.5
Front fork damper rod bolt 40 4.0 29.0
Front fork upper clamp bolt 23 2.3 16.5
Front fork lower clamp bolt 30 3.0 21.5
Front fork inner rod lock-nut 15 1.5 11.0
Steering stem head nut 90 9.0 65.0
Steering stem nut 45 4.5 32.5
Front master cylinder mounting bolt 10 1.0 7.0
Front brake caliper mounting bolt 39 3.9 28.0
Brake hose union bolt 23 2.3 16.5
Air bleeder valve 7.5 0.75 5.5
Handlebar set bolt 23 2.3 16.5
Handlebar holder nut 45 4.5 32.5
Front footrest bracket mounting bolt 55 5.5 40.0
Frame down tube mounting bolt (M8) 23 2.3 16.5
Frame down tube mounting bolt (M10) 50 5.0 36.0
Rear brake pedal bolt 11 1.1 8.0
Rear swingarm pivot bolt (Left) 100 10.0 72.5
Rear swingarm pivot bolt (Right) 9.5 0.95 7.0
Rear swingarm pivot bolt lock nut 100 10.0 72.5
Rear shock absorber mounting nut
(Upper and Lower)
50 5.0 36.0
Rear cushion lever/rod mounting nut 78 7.8 57.5
Rear axle nut 65 6.5 47.0
Rear torque link nut (front) 35 3.5 25.5
Rear torque link nut (rear) 25 2.5 18.0
Rear brake link pivot bolt 29 2.9 21.0
Rear brake cam lever bolt 10 1.0 7.3
Driven joint stopper bolt 10 1.0 7.0
Frame handle grip mounting bolt (M10) 50 5.0 36.0
Fuel level gauge mounting bolt 10 1.0 7.0
SAMPLE

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
