3-8 ENGINE
ENGINE INSTALLATION
Install the engine in the reverse order of engine removal.
Pay attention to the following points:
• Install the universal joint.
NOTE:
Be sure to face the short portion A backward when installing it.
• Install the boot.
NOTE:
Make sure that the “UP” mark B faces up.
• Gradually raise the engine, and then engage the secondary
driven gear shaft to the universal joint.
• Properly fit the boot onto the engine and the swingarm.
• Install the engine mounting bolts and nuts and tighten them.
SAMPLE

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
