Suzuki Intruder VZ800 User Manual

2-10 PERIODIC MAINTENANCE

• Rotate the generator rotor 450 degrees (1 and 1/4 turns) and
align the “F I T” line on the rotor with the center of hole on the
generator cover.
Inspect the No. 2 engine’s valve clearance as the same manner
above.
NOTE:
Use the thickness gauge from the arrow marks as shown in the
illustration.
FUEL HOSE
Inspect the fuel feed hose for damage and fuel leakage. If any
defects are found, the fuel hoses must be replaced.
Both right and left valve clearances should be as
closely set as possible.
FT
FRONT
No. 2 Engine No. 1 Engine
Inspect every 6 000 km (4 000 miles, 12 months).
SAMPLE

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
