8-36 CHASSIS
REASSEMBLY AND REMOUNTING
Reassemble and remount the rear wheel in the reverse order of
removal and disassembly. Pay attention to the following points:
WHEEL BEARING
• Apply grease to the bearings before installation.
 99000-25030: SUZUKI SUPER GREASE “A” (USA)
99000-25010: SUZUKI SUPER GREASE “A” (Others)
• Install the wheel bearings with the special tool.
 09941-34513: Bearing installer set

WHEEL DAMPER
• Install the dampers.
NOTE:
If soap water is applied around the damper, it makes the job
easier.
* First, install the right wheel bearing, then install the
left wheel bearings.
* The sealed cover on the bearing must face out.
Left
Right
Spacer
Left
Right
Clearance
SAMPLE

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
