Name: Suzuki Intruder VZ800
Brand: Suzuki
Rating: 4 (1 reviews)

To Next Page

To Previous Page

10-28 SERVICING INFORMATION

FRAME HEAD COVER CUSHION INSTALLATION

LEFT SIDE COVER CUSHION INSTALLATION

1 Cushion 4 5 mm (0.20 in) 7 10 mm (0.39 in)

2 3 mm (0.12 in) 5 15 mm (0.59 in)

3 12 mm (0.47 in) 6 20 mm (0.79 in)

1 Cushion 2 27 mm (1.06 in) 3 35 mm (1.38 in)

SAMPLE

Questions and Answers:

Need help?

Do you have a question about the Suzuki Intruder VZ800 and is the answer not in the manual?

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
