10-40 SERVICING INFORMATION
SECONDARY AND FINAL
FI SYSTEM AND INTAKE AIR SYSTEM
COOLING SYSTEM
ITEM
N·m kgf-m lb-ft
Secondary drive bevel gear bearing retainer bolt 23 2.3 16.5
Secondary driven bevel gear bolt 23 2.3 16.5
Secondary driven bevel gear bearing stopper 105 10.5 76.0
Secondary drive gear shaft nut 105 10.5 76.0
Final gear case nut 40 4.0 29.0
Final drive bevel gear coupling nut 100 10.0 72.5
Final drive bevel gear bearing stopper 110 11.0 79.5
Final gear case oil drain plug 23 2.3 16.5
Final gear case bolt 8 mm 23 2.3 16.5
10 mm 50 5.0 36.0
Final driven bevel gear bearing retainer screw 9 0.9 6.5
ITEM
N·m kgf-m lb-ft
CKP sensor mounting bolt 8 0.8 6.0
IAT sensor 18 1.8 13.0
Fuel delivery pipe mounting screw 3.5 0.35 2.5
Fuel pump mounting bolt 10 1.0 7.0
TPS and STPS mounting screw 3.5 0.35 2.5
ITEM
N·m kgf-m lb-ft
Water pump cover bolt 6 0.6 4.5
Water pump mounting screw 10 1.0 7.0
Cooling fan thermo-switch 17 1.7 12.5
ECT sensor 18 1.8 13.0
SAMPLE

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
