11-4 EMISSION CONTROL INFORMATION
NOISE EMISSION CONTROL SYSTEM
TAMPERING WITH THE NOISE CONTROL SYSTEM PROHIBITED: Local law prohibits the following acts
or the causing thereof:
1. The removal or rendering inoperative by any person, other than for purposes of maintenance, repair or
replacement, of any device or element of design incorporated into any new vehicle for the purpose of
noise control prior to its sale or delivery to the ultimate purchaser or while it is in use, or
2. The use of the vehicle after such device or element of design has been removed or rendered inoperative
by any person.
AMONG THOSE ACTS PRESUMED TO CONSTITUTE TAMPERING ARE THE ACTS LISTED BELOW:
• Removing or puncturing the muffler, baffles, header pipes, screen type spark arrester (if equipped) or any
other component which conducts exhaust gases.
• Removing or puncturing the air cleaner case, air cleaner cover, baffles or any other component which
conducts intake air.
• Replacing the exhaust system or muffler with a system or muffler not marked with the same model spe-
cific code as the code listed on the Motorcycle Noise Emission Control Information label.
EVAPORATIVE EMISSION CONTROL SYSTEM (Only for E-33)
1 Fuel-vapor separator
2 IAP sensor
3 Throttle body
4 3-way connector
5 Purge hose
6 Fuel shut-off valve
7 Surge hose (red stripe)
8 EVAP canister
A FRESH AIR
B HC VAPOR
C VACUUM
SAMPLE

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
