11-8 EMISSION CONTROL INFORMATION
HEATED OXGEN SENSOR (HO2S) INSPECTION (FOR E-02, 19, 24)
• Disconnect the HO2 sensor lead wire coupler. (5-69)
• Inspect the HO2 sensor and its circuit referring to flow table of
the malfunction code C44 (P0130/P0135).
• Check the resistance between the terminals of the HO2 sen-
sor.
 Resistance: 6.5 – 8.9 Ω at 23 °C (73.4 °F)
(White – White)
 09900-25008: Multi-circuit tester set
 Tester knob indication: Resistance (Ω)
If the resistance is not within the standard range, replace the
HO2 sensor with a new one.
NOTE:
* Temperature of the sensor affects resistance value largely.
* Make sure that the sensor heater is at correct temperature.


Do not remove the HO2 sensor while it is hot.
Be careful not to expose it to excessive shock.
Do not use an impact wrench while removing or
installing the HO2 sensor unit.
Be careful not to twist or damage the sensor lead wire.
White
White
SAMPLE

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
