10-22 SERVICING INFORMATION

SPEED SENSOR HARNESS ROUTING

FRONT TURN SIGNAL INSTALLATION

Pass through the speed sensor harness in front of the brake hose

and guide.

5 Clamp

2 Pass through the speed sensor harness in front of the brake hose. 6 Clip

3 Do not catch the speed sensor harness to the caliper boss. 7 Ye l l o w m a r k

4 Touch the stopper 8 Guide

1 No slack

FWD

SAMPLE

Questions and Answers:

Need help?

Do you have a question about the Suzuki Intruder VZ800 and is the answer not in the manual?

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
