7-6 COOLING AND LUBRICATION SYSTEM

WATER HOSE AND RESERVOIR TANK

INSPECTION

• Remove the fuel tank. (6-3)

• Remove the secondary gear case cover. (8-40)

• Remove the frame head covers. (3-3)

• Any water hose and reservoir tank 1 found in a cracked con-

dition or flattened must be replaced.

• Any leakage from the connecting section should be corrected

by proper tightening.

SAMPLE

Questions and Answers:

Need help?

Do you have a question about the Suzuki Intruder VZ800 and is the answer not in the manual?

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
