7-16 COOLING AND LUBRICATION SYSTEM
OIL SEAL
• Visually inspect the oil seal for damage, with particular atten-
tion given to the lip.
• Replace the oil seal that shows indications of leakage.
BEARING CASE
• Visually inspect the bearing case for damage.
• Replace the water pump body if necessary.
REASSEMBLY AND INSTALLATION
• Install the oil seal with the special tool.
 09913-70210: Bearing installer set
NOTE:
The stamped mark on the oil seal faces outside.
• Apply a small quantity of the SUZUKI SUPER GREASE “A” to
the oil seal lip.
 99000-25030: SUZUKI SUPER GREASE “A” (USA)
99000-25010: SUZUKI SUPER GREASE “A” (Others)
SAMPLE

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
