8-8 CHASSIS
INSPECTION
WHEEL BEARINGS
Inspect the play of the wheel bearings by finger while they are in
the wheel. Rotate the inner race by finger to inspect for abnor-
mal noise and smooth rotation.
Replace the bearing in the following procedure if there is any-
thing unusual.
WHEEL BEARINGS REMOVAL
• Remove the wheel bearings by with the special tool A or B.
 09921-20240: A Bearing remover set (17 mm)
or 09941-50111: B Wheel bearing remover

FRONT WHEEL
Make sure that the wheel runout (axial and radial) does not
exceed the service limit when checked as shown. An excessive
amount of runout is usually due to worn or loose wheel bearings
and can be corrected by replacing the bearings. If bearing
replacement fails to reduce the runout, replace the wheel with a
new one.
 Wheel rim runout (axial and radial)
Service Limit: 2.0 mm (0.08 in)
The removed bearings should be replaced with new
ones.
SAMPLE

Suzuki Intruder VZ800 Specifications

General

Engine Type	4-stroke, liquid-cooled, DOHC, 45-degree V-twin
Displacement	805 cc
Bore x Stroke	83.0 mm x 74.4 mm
Compression Ratio	9.4:1
Fuel System	Fuel injection
Ignition	Electronic ignition (transistorized)
Transmission	5-speed constant mesh
Final Drive	Shaft drive
Front Suspension	Telescopic, coil spring, oil damped
Rear Suspension	Link type, coil spring, oil damped
Rear Brake	Drum brake
Seat Height	700 mm (27.6 in)
Front Brake	Disc brake
Rear Tire	170/80-15M/C 77H, tube type
Fuel Tank Capacity	15.5 L (4.1 US gallons)
