• When booklets exit the SquareFold
®
Trimmer device, they can contain trim remnants or scraps from the
previously trimmed booklet. Static electricity causes this build-up and it is normal. If booklets contain trim
remnants, remove and discard the remnants.
• The trim feature can be enabled or disabled. When the feature is enabled, you can adjust the trim setting in 0.1
mm (0.0039 in.) increments, depending on your requirements for the finished booklet job.
The trim options include the following:
• TTrriimmmmiinngg OOnn // OOffff: This option enables or disables the trimming feature. The default setting is Off.
• CCuutt ttoo SSiizzee: This option decreases or increases the trimmer setting. To decrease or increase the trimmer setting,
use the left and right arrow buttons. Adjustments are made in 0.1 mm (0.0039 in.) increments.
The trim setting is based on the following:
• The number of sheets in the finished booklet
• The width of the finished booklet
• The media type, coated or uncoated
• The media weight
Note:
• To determine the best selections for your job, experiment with various settings. For the best booklet
output, before running larger jobs, run one or more test prints.
• Trim settings cannot be adjusted to remove less than 2 mm (0.078 in.) or more than 20 mm (0.787 in.)
of edge material from the booklet. Adjustments less than 2 mm (0.078 in.) can produce poor trim
quality. Adjustments greater than 20 mm (0.787 in.) result in no trimming to the booklet edge.
Trim Guidelines
The following table shows various scenarios using different paper weights, media types, and trim setting selections.
Use this table as a guideline when selecting a trim setting for your specific job.
Note: The settings shown in the following table are provided as examples and are not meant to represent
every possible job scenario.
SSCCEENNAARRIIOO
NNUUMMBBEERR
PPAAPPEERR SSIIZZEE
FFIINNIISSHHEEDD
BBOOOOKKLLEETT SSIIZZEE
PPAAPPEERR
WWEEIIGGHHTT
AAPPPPRROOXXIIMMAATTEE
TTRRIIMM
SSEETTTTIINNGG
NNUUMMBBEERR
OOFF PPAAGGEESS
IINN AA
FFIINNIISSHHEEDD
BBOOOOKKLLEETT
1
A4: 210 x 298 mm
(8.5 x 11 in.)
149 x 210 mm (5.5
x 8.5 in.)
75 g/m
2
; 20 lbs.
130 mm (5.11
in.)
20
2
A4: 210 x 298 mm
(8.5 x 11 in.)
149 x 210 mm (5.5
x 8.5 in.)
90 g/m
2
; 24 lbs.
125 mm (.98
in.)
14
3
A4: 210 x 298 mm
(8.5 x 11 in.)
149 x 210 mm (5.5
x 8.5 in.)
120 g/m
2
; 32
lbs.
135 mm (5.31
in.)
10
472
Xerox
®
PrimeLink
®
B9100/B9110/B9125/B9136 Copier/Printer User Guide
SquareFold
®
Trimmer Module
