Brother PR600 - Cord Grip Attachment

3 - 87
Feed unit
Main unit
Assembly
13
Cord grip attachment
1. Connect the FFC (SML2CD-C) 1 to the connect PCB, and lock the
connector.
2. Connect the X-feed motor's lead wire to the connect PCB.
3. Bind the X-feed motor's lead wire and the FFC (SML2CD-C) with the cord
grip 2, and then tighten the screw 1.
*Key point
• Insert the X-feed motor's lead wire into the groove 3 on Y-
carriage L.
Start movie clip (CD-ROM version only)
1
Torque
0.59 – 0.78 N-m
1
3
1 2
Screw, Bind
M3X4
Color; Silver
