Brother PR600 Service Manual

4 - 16
Adjustment Motor belt tension adjustment
1. Loosen the 2 screws
1
.
2. Move the motor holder up and down to adjust the motor belt tension.
3. Tighten the 2 screws
1
.
Motor belt deflection when a load of approx. 0.98
N (100 g) is applied to the center of the motor
belt
1.5 - 3.5 mm
1
Torque
1.18 - 1.57 N-m
Upset
4X12DB
Color; Gold
0.98N (100g)
1.5 - 3.5mm
1

Brother PR600 Specifications

General

Type	Embroidery machine
LCD Screen	Yes
USB Port	Yes
Built-in Memory	Yes
Connectivity	USB
Maximum Embroidery Area	200mm
Embroidery Area	200mm
Needle Count	6 needles
