Brother PR600 Service Manual

4 - 22
Adjustment Rotary hook stopper clearance adjustment
1. Loosen the screw
1
and
2
.
2. Adjust the clearance between the rotary hook stopper and the rotary hook.
3. Tighten the screws
1
and
2
.
Clearance between rotary hook stopper end face
and rotary hook
0.65 - 0.95 mm
1
Torque
0.59 - 0.78 N-m
2
Torque
0.59 - 0.78 N-m
Bolt, Socket
M3X6
Color; Black
Screw, P/F
Color;
0.65 - 0.95mm
Rotary hook stopper
Rotary hook
12
