Adjustment
Precaution Adjustment flow ................................4 - 2
Inspection Bent needle ......................................4 - 3
Blunt needle......................................4 - 4
Test mode
Starting test mode / Selecting adjustment test mode
4 - 5
Main board test mode.......................4 - 6
Panel board test mode ...................4 - 12
How to read needle bar numbers on bar code
.4 - 15
Adjustment Motor belt tension adjustment ........4 - 16
Timing belt tension adjustment.......4 - 17
Needle position adjustment (front/back)
..4 - 18
Needle position adjustment (right/left)
..4 - 19
Needle bar rising length and needle space adjustment
....4 - 20
Needle bar height adjustment.........4 - 21
Rotary hook stopper clearance adjustment
..4 - 22
Presser foot height adjustment.......4 - 23
Needle bar top dead center adjustment
...4 - 24
Needle threader adjustment (up/down)
...4 - 25
Check
Needle threader adjustment (right/left)
....4 - 26
Adjustment Needle threading check..................4 - 27
Y-belt tension adjustment ...............4 - 28
X-belt tension adjustment ...............4 - 29
Picker activation adjustment...........4 - 30
Movable knife origin adjustment .....4 - 31
Thread presser base up/down position adjustment
....4 - 32
Hoop sensor adjustment.................4 - 33
XY-guide origin adjustment ............4 - 34
