Chapter 5 Components and Functions (Theory) 5-45
Section 5-8
Top Console
The Top Console includes a Stand By/On switch, a keyboard, different controls for manipulating the
picture quality, and controls for use in Measure & Analyze (M&A).
BT’03 Consoles added a USB connector to the Upper Op Panel for the Wired Voice Scan Option.
Figure 5-31 Top Console
Figure 5-32 BT’03 Top Console
