6-6 Section 6-5 - Z-Release Cable and Gas Spring Adjustment
Section 6-5
Z-Release Cable and Gas Spring Adjustment
The operator panel can move up and down (Z direction). A gas spring in the scanner provides a counter
force to "balance" the weight of the operator panel and allows for positioning with minimal effort. A lever
on the main handle has a cable (similar to a bicycle cable) that provides the release for the gas spring.
This cable has one end attached to the release lever and the other end attached to the mechanism on
the gas spring piston.
6-5-1 Time Required
Approximately 1 person for 1 hour plus travel.
6-5-2 Tools
Phillips screwdriver
10mm open-end wrench
Two (2) small slotted screwdrivers
Needle-nose pliers
Small ruler
Large slotted screwdriver
3mm Allen wrench
6-5-3 Preparations
1.) Power Off / Shutdown the scanner as described in Section 4-3-2 “Power Off / Shutdown” on
page 4-3.
Select the movie camera icon to view the video of the z- release
cable and gas spring adjustment procedure.
4 minutes and 47 seconds
DANGER
DANGEROUS VOLTAGES ARE PRESENT IN THIS EQUIPMENT. COMPLETELY
POWER OFF AND SHUTDOWN THE SCANNER BEFORE SERVICING.
