GE LOGIQ 9 User Manual

GE MEDICAL SYSTEMS PROPRIETARY TO GE
D
IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL
5-52 Section 5-13 - Power Distribution
Section 5-13
Power Distribution
5-13-1 Basic Overall AC Power Distribution
Figure 5-38 Overall Power Distribution
Select AC
Voltage for
Peripherals on
AC Distrubution
Box (PWB):
115 VAC or 230
VAC.
Filter
Mains Power
Breaker
Inrush
Limit
115 or 230
VAC
Transformer
20 VAC
230 VAC
115 VAC
Fan Regulator
Fan
DC Power
TX Power
DC
Voltages to
Cards
Front-End Proccessor
DC Power distribution
inside Back-End
Processor
Back-End Processor
AC/DC
Converter
Modem
VCR
(Video Cassette Recorder)
Black & White Printer
Color Video Printer
TX Voltages
230 VAC
230
VAC
230 VAC
115 VAC
230 VAC
Monitor
Battery
AC/DC
UPS
IIO
Select
Voltage
AC Distrubution Box (PWB)
Transformer Box
Not Used
AC Distri-
bution Box
DC/AC
NOTE: Modem with AC/DC Converter and
cables are optional (used for InSite).
