GE MEDICAL SYSTEMS PROPRIETARY TO GE
D
IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL
7-20 Section 7-7 - Acquisition Diagnostics
7-7-3 Diagnostic Listings
Table 7-2 Acquisition Diagnostics and Utility Listing
Diagnostic/Utility Function
Troubleshoot All Acquisition
Diagnostics
Runs all Acquisition Hardware diagnostics and isolates faults to a FRU.
Overnight Reliability Test
Runs all diagnostics and records a running log.
SCB PCI Interface Diag
Tests the host’s ability to communicate with the SCB via the secondary PCI bus
SCB Memory Diag
Tests all of the on-board memory, including registers.
SCB DSP Diag
Tests the Scan Sequencer’s DSP and associated components.
SCB Scan Bus Diag
Tests the local Scan Bus and the associated system timing.
SCB Image Port Diag
Tests the Image Port’s functionality.
BMP PCI Interface Diag
Tests the host’s ability to communicate with the BMP via the PCI bus.
BMP Memory Diag
Tests all of the on-board memory, including registers.
BMP Signal Path Diag
Tests the entire BMP signal path.
EQ PCI Interface Diag
Tests the host’s ability to communicate with the registers and memory on the EQ via
the PCI bus.
EQ Memory Diag
Tests all of the on-board memory, including registers.
EQ Signal Path Diag
Tests the entire EQ signal path.
TD Memory Diag
Tests all of the on-board memory, for all installed TD boards, including registers.
TD Access Diag
Tests all of the Access Modes utilized for Host/TD communication as well as Channel
RAM to Rigel transfers.
XDIF Interface Diag
Tests all of the XDIF functionality that is testable without a probe or probe simulator
attached to the system, including the IIC communication.
Comprehensive Signal Path Diag
Tests the signal path of every channel from the TD Rigel Transmitter Memories to the
SCB, via both the EQ and the BMP.
TD Analog Reference Diag
Tests the AD_REF and VREF voltages on the TD.
Analog TGC Diag
Tests the generation of the analog TGC voltage.
Power Supply Diag
Tests the system voltages available on the EQ.
Temperature Diag
Tests the temperature of the system, wherever available.
Noise Floor Diag
Measures the noise floor of the system. The noise floor will be calculated form IQ data
received without a signal source.
Loopback Diag
Tests the analog front-end of the system.
Acquisition Hardware Information Utility Writes a file for each Acquisition Hardware FRU containing all Vital Product Data.
Transmit Utility - Start
Transmit Utility - Change Channel
Transmit Utility - Stop
Receive Utility - Single Frame Receives signal on one channel at a time.
Receive Utility - 8 Frames
Visual Channel Utility
