GE MEDICAL SYSTEMS PROPRIETARY TO GE
D
IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL
Chapter 7 Diagnostics/Troubleshooting 7-19
4.) Loop Count
- This is an editable text field that will only accept numeric values of 4 digits or less. When the
switch is configured as an “execute” switch and pressed, the loop count field will be queried
to determine the number of times to execute the diagnostic.
5.) Progress Indicator
- Displays a graphical progress indicator for the user.
6.) Short Text Message
- Displays brief messages about the test’s progress during execution.
7.) Status Frame Background Color
- Initially gray, the Status Frame background color changes upon completion of a diagnostic to
indicate completion status.
- Code Status Fail = Red
- Code Status Pass = Green
- Code Status neither Pass nor Fail (Example: Aborted) = Gray (default color).
7-7-2 Reliability Testing
Overnight relialibility test.
- Runs all diagnostics. Logs ALL
results. Results accumulate in the log each time the tests are
run. The log file continues to grow.
NOTE: This is not intended for field service use. Typically a manufacturing test.
