GE MEDICAL SYSTEMS PROPRIETARY TO GE
D
IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL
Chapter 3 Installation 3-9
Section 3-6
System Configuration
3-6-1 System Specifications
3-6-1-1 Physical Dimensions Physical Dimensions of
The physical dimensions of the LOGIQ™ 9 unit are summarized in Ta b l e 3- 1 and Tabl e 3- 2 .
Table 3-1 lists the size of LOGIQ™ 9, with monitor and on-board peripherals.
3-6-1-2 Weight without Monitor and Peripherals
3-6-1-3 Acoustic Noise Output:
Less than 70dB(A) according to DIN 45635 - 19 - 01 - KL2.
3-6-2 Electrical Specifications
3-6-3 On-Board Optional Peripherals
NOTE: There are no external peripheral options for the LOGIQ™ 9
Table 3-1 Physical Dimensions of LOGIQ™ 9
Height
Width Depth
Minimum Maximum
140.3 cm / 55.25 inches 160.7 cm / 63.25 inches 64 cm / 25.2 inches 89.9 cm / 35.4 inches
Table 3-2 Weight of LOGIQ™ 9 With Monitor and Without Other Peripherals
Model Weight [kg] Weight [lbs.]
LOGIQ™ 9 196.8 434
Table 3-3 Electrical Specifications for LOGIQ™ 9
Voltage Tolerances Current Frequency
100-120 VAC ±10% 9.5 A 50-60 Hz
200-240 VAC ±10% 4.75 A 50-60 Hz
Table 3-4 Approved Peripherals
Device Manufacturer Model Video Signal
B/W Video Printer SONY UP-895MDW NTSC/PAL
Video Cassette Recorder SONY
SVO-9500MD
SVO-9500-MDP
NTSC
PAL
Video Cassette Recorder Panasonic
AG-MD835
AG-MD835P
AG-MD835E
NTSC
NTSC
PAL
