IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL
Chapter 8 Replacement Procedures 8-111
Section 8-27
Lower Operator Panel Replacement Procedure
8-27-1 Manpower
One person, 2 hours
8-27-2 Tools
Phillips screwdriver size 2
8-27-3 Preparations
1.) Shut down the system as described in Power Off / Shutdown on page 4-3.
Figure 8-121 Operator Panel
Screws, 16mm
Screws 6 mm
Operator Panel
LCD Display
Screws 25mm
Screws, 16mm
