GE MEDICAL SYSTEMS PROPRIETARY TO GE
D
IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL
Chapter 8 Replacement Procedures 8-157
8-38-4 Brake pedal and Direction Lock Removal Procedure
1.) Unscrew 2 nuts on the two ball joints on the brake rods, located over the middle of brake assembly.
2.) Unscrew the 4 hexagon screws. Two of them located under the Brake Assembly.
NOTE: The nuts may slide out of position.
3.) Remove the Brake Pedal and Direction Lock Assembly.
8-38-5 Brake pedal and Direction Lock Installation procedure
1.) Put the Brake Pedal and Direction Lock Assembly in position and fasten the 4 hexagon screws
loosely in the sliding nuts.
2.) Fasten the ball joint nuts before tightening the 4 hexagon screws.
3.) Install Front Bumper .
4.) Fasten footrests to Brake Pedal and Direction Lock Assembly. Fasten the screws gently.
