GE MEDICAL SYSTEMS PROPRIETARY TO GE
D
IRECTION 2294854-100, REVISION 3 LOGIQ™ 9 PROPRIETARY MANUAL
Chapter 5 Components and Functions (Theory) 5-49
5-10-4 Output Signals
Several signal are fed from the Internal I/O board to an External I/O board located on the rear of the
system. This board contains data buffers and a galvanic isolation section.
Different types of signals are fed to connectors accessible on the External I/O.
• R, G, B and Sync are provided for external RGB monitors or printers.
• Composite video, black and white video and S-VHS video are buffered and fed to output connectors
for external monitors and printers.
• Two serial RS-232 ports are provided for external communication with e.g. the System CPU.
• An Ethernet signal from the BEP is fed to an Ethernet connector. It is used for connectivity, including
DICOM Network.
Section 5-11
Peripherals
A VCR, an analog or digital Black-and-White Video Printer and an analog or digital Color Printer may
be installed on the scanner. These devices receive video signals from the Internal I/O Board and power
from the AC Control Box.
Peripherals are gemerally specified and approved regionally.
BT’02 (BEP 2.1 and above) systems have digital peripheral capabilities through USB or USB To SCSI
converters.
Table 5-31 Output Signals
Signal Name Description Signal Path
Stereo Audio
Stereo audio to external VCR. (Same signal as delivered to
internal VCR).
Audio Source (Internal VCR/
Microphone/BEP) > Internal
I/O > External I/O > External VCR.
Composite Video
External composite video, 1.0Vp-p, 75 ohms, unbalanced,
sync negative.
PC2IO (BEP) > Internal I/O > External I/
O > External Composite Video Device
Super Video
(SVHS)
Super Video
Luminance: 1.0Vp-p, 75 ohms, unbalanced.
Color: 1.0Vp-p, 75 ohms, unbalanced.
PC2IO (BEP) > Internal I/O > External I/
O > External VCR
Black and White
video
External black and white video
1.0Vp-p, 75 ohms, unbalanced, sync negative.
PC2IO (BEP) > Internal I/O > External I/
O > External B/W Video Device
Trig Trigger Signal, 0-3.3V
SVGA
SVGA (RGBS) high resolution video output
(Same signal as sent to the systems monitor)
PCVIC > PC2IO (BEP) > Internal I/O >
External I/O > External Monitor
Remote Expose #1 A SW controllable relay, to control external peripherals
PC2IO (BEP) > Internal I/O > External I/
O > External Peripheral
Remote Expose #2 A SW controllable relay, to control external peripherals
PC2IO (BEP) > Internal I/O > External I/
O > External Peripheral
