8-136 Section 8-35 - Verify and Update Vital Product Data
8-35-2 Collecting Vital Product Data (cont’d)
Table 8-11 VPD Data Collection
Circuit Board Name Part Number
Functional Revision
PWA Letter
Fab Revision
PWB Number
Bar Code or
Serial Number
Date
YYYYMMDD
BM Processor 2260207 Do Not Update 2 0 0 _ _ _ 01
Backplane 2260219 A 1 012345 2 0 0 _ _ _ 01
Console
From Rating Plate
Only -2 can be entered
N/A N/A 2 0 0 _ _ _ 01
BEP
BEP Rating Plate
Only -3 can be entered
PSP Revison
-2 after upgrade
N/A
No Dash Allowed BEP Rating Plate
2 0 0 _ _ _ 01
Equalization 2260210 2 0 0 _ _ _ 01
EBM 2273639 2 0 0 _ _ _ 01
Power Supply
2260203 / 2273641 /
2376843 / 2260203
2 0 0 _ _ _ 01
RF Amplifier
2260212 / 2341985 /
2357621
2 0 0 _ _ _ 01
Scan Control 2260214 / 2365739 2 0 0 _ _ _ 01
Time Delay 0 2260194 / 2362863 2 0 0 _ _ _ 01
Time Delay 1 2260194 / 2362863 2 0 0 _ _ _ 01
Time Delay2 2260194 / 2362863 2 0 0 _ _ _ 01
Time Delay 3 2260194 / 2362863 2 0 0 _ _ _ 01
Time Delay 4 2260194 / 2362863 2 0 0 _ _ _ 01
Time Delay 5 2260194 / 2362863 2 0 0 _ _ _ 01
Time Delay 6 2260194 / 2362863 2 0 0 _ _ _ 01
Time Delay 7 2260194 / 2362863 2 0 0 _ _ _ 01
Transducer Interface 2260221 2 0 0 _ _ _ 01
PC2IP Not a FRU Part of BEP. Not Updated
