GE P444 User Manual

Setting
P44x/EN ST/Hb
6
MiCOM P40 Agile
P442, P444 (ST) 4-
37
2.14.2 Overfrequency protection
Menu text Default setting
Setting range
Step size
Min Max
GROUP 1 – FREQ PROTECTION
OVERFREQUENCY
F>1 Status Disabled Disabled / Enabled
Setting to enable or disable the first overfrequency element. The F>1 threshold setting and
time-delay (following submenus) are settable when F>1 status is enabled.
F>1 Setting 50.5Hz 45Hz 65Hz 0.01Hz
Setting that determines the pick-up threshold for the first stage overfrequency element.
F>1 Time delay 2s 0s 100s 0.01s
Setting that determines the minimum operating time-delay for the first stage overfrequency
element.
F>2 Status Disabled Disabled / Enabled
Setting to enable or disable the second overfrequency threshold (same setting as stage 1).
F>2 Setting 51Hz 45Hz 65Hz 0.01Hz
F>2 Time delay 1s 0s 100s 0.01s
2.15 Circuit breaker fail protection (CBF) (“CB Fail & I<” menu)
Menu text Default setting
Setting range
Step size
Min Max
GROUP 1 – CB FAIL & I<
BREAKER FAIL
CB Fail 1 Status Enabled Enabled, Disabled
Setting to enable or disable the first stage of the circuit breaker function.
CB Fail 1 Timer 0.2 s 0 s 10 s 0.01 s
Setting for the circuit breaker fail timer stage 1, during which breaker opening must be
detected.
CB Fail 2 Status Disabled Enabled, Disabled
Setting to enable or disable the second stage of the circuit breaker function.
CB Fail 2 Timer 0.4 s 0 s 10 s 0.01 s
Setting for the circuit breaker fail timer stage 2, during which breaker opening must be
detected.
CBF Non I Reset CB Open & I< I< Only, CB Open & I<, Prot Reset & I<,
Prot Reset or I<, Disable
Setting which determines the elements that will reset the circuit breaker fail time for
undercurrent protection function initiated circuit breaker fail conditions.
