GE P444 User Manual

P
44x/EN ST/Hb6
Setting
(ST) 4
-64 MiCOM P40 Agile
P442, P444
3.14 “IED configurator” column (P442 / P444 only)
The contents of the IED CONFIGURATOR column (for IEC 61850 configuration) are mostly
data cells, displayed for information but not editable. to edit the configuration, it is necessary
to use the IED (Intelligent Electronic Device) configurator tool within MiCOM S1 Agile.
Menu Text Default Setting
Setting Range
Step Size
Min. Max.
IED CONFIGURATOR
Switch Conf.Bank No Action No Action, Switch Banks
Setting which allows the user to switch between the current configuration, held in the
Active Memory Bank (and partly displayed below), to the configuration sent to and held in
the Inactive Memory Bank.
Restore MCL No action No action / Restore MCL
Used to restore data from MCL binary file. MCL (MiCOM Configuration Language) files are
specific, containing a single devices IEC61850 configuration information, and used for
transferring data to/from the MiCOM IED.
Active Conf.Name Data
The name of the configuration in the Active Memory Bank, usually taken from the SCL file.
Active Conf.Rev Data
Configuration Revision number of the Active Memory Bank, used for version management.
Inact.Conf.Name Data
The name of the configuration in the Inactive Memory Bank, usually taken from the SCL
file.
Inact.Conf.Rev Data
Configuration Revision number of the Inactive Memory Bank, used for version
management.
IP PARAMETERS
IP Address Data
Displays the unique network IP address that identifies the relay.
Subnet Mask Data
Displays the sub-network that the relay is connected to.
Gateway Data
Displays the IP address of the gateway (proxy) that the relay is connected to.
SNTP PARAMETERS
SNTP Server 1 Data
Displays the IP address of the primary SNTP server.
SNTP Server 2 Data
Displays the IP address of the secondary SNTP server.
IEC61850 SCL
IED Name Data
8 character IED name, which is the unique name on the IEC 61850 network for the IED,
usually taken from the SCL (Substation Configuration Language for XML) file.
IEC61850 GOOSE
