Setting
P44x/EN ST/Hb
6
MiCOM P40 Agile
P442, P444 (ST) 4-
45
Menu Text Default Setting
Setting Range
Step Size
Min. Max.
RECORD CONTROL
System Event Enabled Enabled or Disabled
Disabling this setting means that no System Events will be generated.
Fault Rec. Event Enabled Enabled or Disabled
Disabling this setting means that no event will be generated for any fault that produces a
fault record.
Maint. Rec. Event Enabled Enabled or Disabled
Disabling this setting means that no event will be generated for any occurrence that
produces a maintenance record.
Protection Event Enabled Enabled or Disabled
Disabling this setting means that any operation of protection elements will not be logged
as an event.
Clear Dist Recs No No or Yes
Selecting “Yes” will cause the existing disturbance records to be cleared and an event will
be generated indicating that the disturbance records have been erased.
DDB 31 - 0 11111111111111111111111111111111
Displays the status of DDB signals 0 – 31.
DDB 2047 - 2016 11111111111111111111111111111111
Displays the status of DDB signals2016– 2047.
3.5 Disturbance recorder (“Disturb recorder” menu)
The integral disturbance recorder has an area of memory specifically set aside for record
storage. The number of records that may be stored is dependent on the selected recording
duration but the relays typically have the capability of storing a minimum of 20 records, each
of 10.5 second duration.
NOTE: 1. Compressed Disturbance Recorder used for Kbus/Modbus/DNP3
reach that typical size value (10.5 sec duration)
2. Uncompressed Disturbance Recorder used for IEC 60870-5/103
could be limited to 2 or 3 seconds.
Disturbance records continue to be recorded until the available memory is exhausted, at
which time the oldest record(s) are overwritten to make space for the newest one.
The recorder stores actual samples which are taken at a rate of 48 samples per cycle.
Each disturbance record consists of eight analogue data channels and 64 digital data
channels. Note that the relevant CT and VT ratios for the analogue channels are also
extracted to enable scaling to primary quantities).
Menu Text Default Setting
Setting Range
Step Size
Min. Max.
DISTURB RECORDER
Duration 600 s 100.0 ms 10.5 s 10.00 ms
This sets the overall recording time.
Trigger Position 33.3% 0.0% 100.0% 0.10 %
