44x/EN MR/Hb6
Measurements and Recording
-10
LCD Failure LCD Failure
Watchdog 1 Fail Watchdog 1 Failure (Fast)
Watchdog 2 Fail Watchdog 2 Failure (Slow)
Field Volt Fail Field Voltage Failure
FlashEEPROM Fail Flash EPROM Failure
EEPROM Fail EEPROM Failure
Cal EEPROM Fail Cal EEPROM Failure
Invalid H/W Incorrect Hardware Configuration
Power Up Boot Power Up Boot
Soft Reboot Soft Reboot
Each time a Maintenance Report is generated, an event is also created. The event simply
states that a report was generated, with a corresponding time stamp.
1.2.9 Setting Changes
Changes to any setting within the relay are logged as an event. Two examples are shown in
the following table:
Displayed Text in Event Record
Control/Support Setting C & S Changed
Group 1 / 2 / 3 or 4 Change Group 1, 2, 3 or 4 updated
Disturbance setting Disturbance recorder
Active group change Active group changed
Note: Control/Support settings are communications, measurement, CT/VT ratio settings etc,
which are not duplicated within the four setting groups. When any of these settings
are changed, the event record is created simultaneously. However, changes to
protection or disturbance recorder settings will only generate an event once the
settings have been confirmed at the ‘setting trap’.
1.2.10 Resetting of Event / Fault Records
If it is required to delete either the event, fault or maintenance reports, this may be done from
within the ‘RECORD CONTROL’ column.
1.2.11 Viewing Event Records via MiCOM S1 Agile Support Software
When the event records are extracted and viewed on a PC they look slightly different than
when viewed on the LCD. The following shows an example of how various events appear
when displayed using MiCOM S1 Agile:
Monday 03 November 2010 15:32:49 GMT I>1 Start ON 2147483881
MiCOM
Model Number: P441
Address: 001 Column: 00 Row: 23
Event Type: Protection operation
Monday 03 November 2010 15:32:52 GMT Fault Recorded 0
MiCOM
Model Number: P442
Address: 001 Column: 01 Row: 00
To Next Page
