Introduction
P44x/EN IT/Hb
6
MiCOM P40 Agile P442, P444
(IT) 1-
11
3.1 Ordering options
Distance Protection
P442 P44
2 **
Nominal auxiliary voltage
24-54 Vdc
7
48-125 Vdc (40-100 Vac)
8
110-250 Vdc (100-240 Vac)
9
In/Vn rating
Dual rated CT (1 & 5A : 100 - 120V) 1
Module Sum (∑ 1A / PXDB)
5
C
Hardware options
Standard version
1
IRIG-B Only (Modulated) 2
3
4
Single Ethernet 100Mbit/s 6
Second Rear Comms + InterMiCOM 7
IRIG-B (Modulated) + Second Rear Comms + InterMiCOM 8
Single Ethernet (100Mbit/s) plus IRIG-B (Modulated) Software version '31' and later (Suffix J) A
Single Ethernet (100Mbit/s) plus IRIG-B (Un-modulated) Software version '31' and later (Suffix J) B
IRIG-B (Un-modulated) Software version '31' and later (Suffix J) C
InterMiCOM + Courier Rear Port * E
InterMiCOM + Courier Rear Port + IRIG-B modulated *
F
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Modulated IRIG-B G
Redundant Ethernet Self-Healing Ring, 2 multi-mode fibre ports + Un-modulated IRIG-B H
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Modulated IRIG-B J
Redundant Ethernet RSTP, 2 multi-mode fibre ports + Un-modulated IRIG-B K
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Modulated IRIG-B L
Redundant Ethernet Dual-Homing Star, 2 multi-mode fibre ports + Un-modulated IRIG-B M
Redundant Ethernet PRP/HSR**, 2 fibre ports + Modulated IRIG-B
N
Redundant Ethernet PRP/HSR**
, 2 fibre ports + Unmodulated IRIG-B P
* NB: Options available with Software version 45 & later (Design Suffix K)
** For HSR – contact Alstom for details
Software options
16 Logic Inputs & 21 Relay Outputs B
16 Logic Inputs & 21 Relay Outputs (3 Fast trip) D
16 Logic Inputs & 21 Relay Outputs (6 Fast trip) E
16 Logic Inputs & 18 Relay Outputs (4 High Break) *
C
* NB: Option C is only available with Design Suffix K & Software version 40 or later
Protocol options
K-Bus 1
Modbus
2
VDEW (IEC 60870-5-103)
3
DNP3.0 4
UCA2 + Courier via rear RS485 port (Ethernet hardware options [i.e. 6] only) 5
IEC61850 + Courier via rear RS485 port * 6
IEC61850 + IEC60870-5-103 via rear RS485 port * 7
DNP3 over Ethernet with Courier rear port K-Bus/RS485 protocol
8
* NB: IEC61850 Edition 2 available with '82' Software
Mounting
Flush Panel Mounting, with Harsh Environment Coating M
Language
English, French, German, Spanish
0
English, French, German, Italian 4
C
Software version
Date and application dependant **
Customer specific options
Standard version 0
Customer engineered version: ENEL 1
Customer engineered version: TERNA 2
Customer engineered version: RTE 4
Customer engineered version: general A
Hardware version
Model and hardware version dependant *
Chinese, English or French via HMI, with English or French only via
Communications port
Variants Order No.
Fibre optic converter (Courier, Modbus,IEC60870-5-103 or DNP3)
(Note: converts RS485 port to fibre optic; NOT extra port
)
IRIG-B input and Fibre optic converter (Courier, Modbus,IEC60870-5-103 or DNP3)
(
Note: converts RS485 port to fibre optic; NOT extra port)
Non-conventional input transformers NCIT (IEC 61850-9-2 LE)
