5 Motor control & motor settings
5.11 Setting control loops
117
Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
0x2941 | 0x3141 - Current controller: Feedforward control
0x2942 | 0x3142 - Current controller: Parameter
0x2943 | 0x3143 - Motor: Current setpoint - filter time
Activate/deactivate the current controller feedforward control
• Since the positioning movements are known, they can be precontrolled in order to slightly increase the
achievable dynamic performance of the control loop.
Note!
A successful feedforward control requires knowledge of the equivalent circuit data of the motor. If only estimated
values are available, the feedforward control should not be activated.
Selection list (Lenze setting printed in bold)
0Off
1Activate
 Write access  CINH  OSC  P  RX  TX UNSIGNED_8
Sub. Name Lenze setting Data type
1 Current controller: Gain 148.21 V/A UNSIGNED_32
2 Current controller: Reset time 3.77 ms UNSIGNED_32
Subindex 1: Current controller: Gain
Setting range (min. value | unit | max. value) Lenze setting
0.00 V/A 750.00 148.21 V/A
 Write access  CINH  OSC  P  RX  TX Scaling: 1/100 UNSIGNED_32
Subindex 2: Current controller: Reset time
Setting range (min. value | unit | max. value) Lenze setting
0.01 ms 2000.00 3.77 ms
 Write access  CINH  OSC  P  RX  TX Scaling: 1/100 UNSIGNED_32
Setting range (min. value | unit | max. value) Lenze setting
0.00 ms 10.00 0.00 ms
 Write access  CINH  OSC  P  RX  TX Scaling: 1/100 UNSIGNED_16
