3 Communication with the controller
3.6 Ethernet over EtherCAT (EoE)
33
Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.6.2 Supported protocols and services
•ARP
•DHCP Client
•ESDCP
•ICMP (ping)
•IP
•UDP/TCP
• GCI-SDO communication (TCP port 9410)
3.6.3 Display of EoE-specific information
The following object serves to read out the EoE-specific information for diagnostic purposes.
0x2020 - EoE information
From version 01.05
• The subcodes 1 ... 6 display the IP and Ethernet settings configured by the control during initialisation.
• The subcodes 7 and 8 display the traffic via EoE in Rx and Tx direction. The displayed values can be reset to "0" by
entering any value.
Sub. Name Lenze setting Data type
1 Virtual MAC address STRING(32)
2 IP address STRING(32)
3 Subnet mask STRING(32)
4 Standard gateway STRING(32)
5 DNS server STRING(32)
6 DNS name STRING(50)
7 Data packets received UNSIGNED_32
8 Data packets transmitted UNSIGNED_32
 Write access  CINH  OSC  P  RX  TX
