9.2 Indication of fault and warning (error code)
The indication of fault and warning is implemented according to CiA 301/402:
• In the error-free state, error code "0" is displayed.
• The fault/warning that has occurred first is always displayed.
• Faults overwrite warnings.
• In general, warnings do not lock up the system. If the cause of the warning disappears, the i700
servo inverter resets the warning display and bit 7 in the Statusword (0x6041
or 0x6841 for axis
B) after the PDO update has been carried out in the direction of control flow.
0x603F | 0x683F - Error code
 Tip!
Chapter "CiA402 error codes / error messages
" lists all possible error codes of the i700 servo
inverter including causes and possible remedies.
0x284F | 0x304F - Current fault
Further indications of faults and warnings
• In the Statusword (0x6041
or 0x6841 for axis B)
• a fault is indicated via bit 3,
• a warning is indicated via bit 7.
• Further diagnostics can be carried out with the history buffer (0x10F3
). It contains the last 32
messages of the i700 servo inverter.
Display area (min. value | unit | max. value) Initialisation
0x0000 0xFFFF 0x0000
 Write access  CINH  OSC  P  RX  TX UNSIGNED_16
From version 01.06
Text display of the current error
• This object contains a reference to the text to be displayed from the ESI file as well as the replacement values for
all wildcards in this text.
• The text has the same structure as the diagnostics messages in the history buffer
.
 Write access  CINH  OSC  P  RX  TX ARRAY [0..63] OF BYTE
 Document "ETG.1020 Protocol Enhancements"
See chapter 13.3 of document "ETG.1020 Protocol Enhancements" provided by the
EtherCAT Technology Group (ETG) for detailed information on the structure of the
diagnostic messages.
