Lenze i700 User Manual

Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06 49
4 Device settings
4.5 Monitoring of the DC-bus voltage
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.5 Monitoring of the DC-bus voltage
For the device as a whole, the DC-bus voltage is monitored with regard to undervoltage and
overvoltage.
Monitoring of the warning thresholds
The warning thresholds for the monitoring are adjustable and preset for a rated mains voltage of
400 V in the Lenze setting.
Voltage monitoring of the warning thresholds is active in the "Ready to switch on
", "Switched on",
"Operation enabled
", and "Quick stop active" device states.
Monitoring of the error thresholds
• Up to and including version 01.06, the error monitoring function is active in the "Ready to switch
on", "Switched on", "Operation enabled", and "Quick stop active" device states.
• From version 01.07 onwards, voltage monitoring of the error thresholds is active in the
"Operation enabled
" and "Quick stop active" device states.
The error thresholds for the monitoring process are determined on the basis of the rated mains
voltage set:
*)
Only permissible for setting up a system! For all other operating states, this rated voltage is impermissible.
0x2540 - Device: Voltage values
Mains Undervoltage thresholds Overvoltage thresholds
Rated
voltage
0x2540:1
Warning threshold
0x2540:2
Error threshold
0x2540:3
Threshold "Reset
error"
0x2540:4
Warning threshold
0x2540:5
Error threshold
0x2540:6
Threshold "Reset
error"
0x2540:7
0: 230 V
eff
430 V 200 V 225 V 795 V 800 V 790 V
1: 400 Veff
285 V 430 V 800 V 790 V
2: 480 V
eff
490 V 535 V 800 V 790 V
4: 60 V
*)
10 V 15 V 60 V 50 V
10: 230 V
eff
Reduced LU
threshold
50 V 100 V 800 V 790 V
11: 400 V
eff
Reduced LU
threshold
50 V 200 V 800 V 790 V
12: 480 V
eff
Reduced LU
threshold
50 V 250 V 800 V 790 V
Greyed out = read access only or threshold specified
Sub. Name Lenze setting Data type
1 Mains: Rated voltage 1: 400 Veff UNSIGNED_8
2 Undervoltage (LU): Warning threshold 430 V UNSIGNED_16
3 Undervoltage (LU): Error threshold 285 V UNSIGNED_16
4 Undervoltage (LU): Threshold 'Reset error' 430 V UNSIGNED_16
5 Overvoltage (OU): Warning threshold 795 V UNSIGNED_16
6 Overvoltage (OU): Error threshold 800 V UNSIGNED_16
7 Overvoltage (OU): Threshold 'Reset error' 790 V UNSIGNED_16
8 DC-bus voltage is critical UNSIGNED_8

Lenze i700 Specifications

General

Control Type	Vector control, V/f control
Safety	STO (Safe Torque Off)
Protection Class	IP20
Frequency	50/60 Hz
Communication Interfaces	CANopen
Cooling	Air cooled
Protection Features	Overvoltage, Undervoltage
Ambient Temperature	-10°C to +45°C
Frequency Range	0 Hz to 300 Hz
Supply Voltage	3-phase AC
