Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06 158
5 Motor control & motor settings
5.14 Parameterising the V/f characteristic control
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
5.14.8 Optimising pull-out slip limitation
The following object serves to adapt the pull-out slip function or the maximally permissible motor
current in the field weakening range.
• If the motor is to be stalled in the field weakening range, the override point can be offset by
reducing the value so that a motor stalling can be prevented.
• If the motor cannot provide enough torque in the field weakening range, the value has to be
increased.
0x2B0C | 0x330C - VFC: Override point of field weakening
5.14.9 Display parameter
0x2B0B | 0x330B - VFC: Setpoint frequency
Subindex 4: VFC: Oscillation damping - final ramp frequency
Ramp end frequency from which the gain factor is to have reached its rated value.
• By setting a ramp end frequency, a possible negative impact of the oscillation damping on the concentricity
factor in the lower speed range can be reduced.
• The ramp end frequency refers to the rated motor frequency in percent.
Setting range (min. value | unit | max. value) Lenze setting
0 % 100 0 %
Write access CINH OSC P RX TX UNSIGNED_8
From version 01.03
Offset of the override point for field weakening
Setting range (min. value | unit | max. value) Lenze setting
-500.0 Hz 500.0 0.0 Hz
Write access CINH OSC P RX TX Scaling: 1/10 INTEGER_16
Display area (min. value | unit | max. value) Initialisation
-600.0 Hz 600.0 0.0 Hz
Write access CINH OSC P RX TX Scaling: 1/10 INTEGER_16
