Lenze i700 User Manual

3 Communication with the controller
3.6 Ethernet over EtherCAT (EoE)
41
Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.6.4.5 Telegram-example 2: Querying the software version of the i700 (read request)
The software version of the i700 servo inverter is to be read.
• Object to be read: 0x100A
• Assumption: Software version = "1.5.0.9999 (release)"
Request
• SDO command (GSV) = 0x82 = "Read parameter"
• GCI Message Qualifier (GMQ) = 0x00 = 0b00000000 = "Request"
• Transaction ID (GTI) here "1" (optional consecutive number 0 ... 255)
• Length of the user data (SIZE) = 0x0014 = 20 bytes
GCI header
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
GMT GSV GMQ GTI SIZE SIZE res res
0x01 0x82 0x00 0x01 0x14 0x00 0x00 0x00
Fixed Read
parameters
Request Transactions ID Length of the user data = 20 bytes Reserved
User data area P0
Byte 1 Byte 2 Byte 3 Byte 4
Reserved Data type Reserved
0x00 0x00 0x00 0x00
Optional for
read request
User data area P1 User data area P2
Byte 1 Byte 2 Byte 3 Byte 4 Byte 1 Byte 2 Byte 3 Byte 4
Index Reserved Subindex Reserved
0x0A 0x10 0x00 0x00 0x00 0x00 0x00 0x00
Index = 0x100A No subindex
User data area P3 User data area P4
Byte 1 Byte 2 Byte 3 Byte 4 Byte 1 Byte 2 Byte 3 Byte 4
Reserved Reserved
0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00

Lenze i700 Specifications

General

Control Type	Vector control, V/f control
Safety	STO (Safe Torque Off)
Protection Class	IP20
Frequency	50/60 Hz
Communication Interfaces	CANopen
Cooling	Air cooled
Protection Features	Overvoltage, Undervoltage
Ambient Temperature	-10°C to +45°C
Frequency Range	0 Hz to 300 Hz
Supply Voltage	3-phase AC
