Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06 306
10 Service/internal
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
0x2DDC | 0x35DC - Slip: Actual slip
0x2DDD | 0x35DD - Device: Actual output frequency
0x2DDE | 0x35DE - motor: Actual position of rotor angle
-3276.7 V 3276.7
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Subindex 5: Q-voltage (torque)
Display area (min. value | unit | max. value) Initialisation
-3276.7 V 3276.7
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Subindex 4: D-voltage (magnetisation)
Display area (min. value | unit | max. value) Initialisation
-3276.7 Hz 3276.7
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Display area (min. value | unit | max. value) Initialisation
-3276.7 Hz 3276.7 0.0 Hz
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 INTEGER_16
Display area (min. value | unit | max. value) Initialisation
0 2047
 Write access  CINH  OSC  P  RX  TX INTEGER_16

Lenze i700 Specifications

General

Control Type	Vector control, V/f control
Safety	STO (Safe Torque Off)
Protection Class	IP20
Frequency	50/60 Hz
Communication Interfaces	CANopen
Cooling	Air cooled
Protection Features	Overvoltage, Undervoltage
Ambient Temperature	-10°C to +45°C
Frequency Range	0 Hz to 300 Hz
Supply Voltage	3-phase AC
