Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06 333
11 Appendix
11.2 Structure of the parameter set file
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
11.2.2 Data header
"PAR_ParamHeader" header type
If the identification "1" is given for the data area type, the parameter values are successively
arranged in the following layout within the data area:
Byte offset
0 4 8
... Type Data start Data size ...
Byte
offset
Meaning Info
0 Type of the data area Identification of the data area
Currently only the following values are defined:
• 1: The data area contains parameter values.
"PAR_ParamHeader" header type
• 2: The data area contains error messages of the last
import.
"PAR_ParamErrorHeader" header type
4 Start of the data area Offset of the data area in [bytes]
(offset from the start of the file).
8 Size of the data area Size of the data area in [bytes]
Byte offset
0 2 4 6
... Data type size Index Subindex Value ...
Byte
offset
Meaning Info
0 Data type size of the parameter Number of bytes which are assigned by the parameter
value.
2 Index of the parameter object Index of the parameter in the object directory which the
following parameter value belongs to.
4 Subindex of the parameter object Subindex of the parameter in the object directory which
the following parameter value belongs to.
6 Parameter value The parameter value assigns the number of data bytes
which are listed under "Data type size of the parameter".
At least, however, always one byte.

Lenze i700 Specifications

General

Control Type	Vector control, V/f control
Safety	STO (Safe Torque Off)
Protection Class	IP20
Frequency	50/60 Hz
Communication Interfaces	CANopen
Cooling	Air cooled
Protection Features	Overvoltage, Undervoltage
Ambient Temperature	-10°C to +45°C
Frequency Range	0 Hz to 300 Hz
Supply Voltage	3-phase AC
