Lenze i700 User Manual

Lenze · i700 servo inverter · reference manual · DMS 3.0 EN · 06/2016 · TD06 130
5 Motor control & motor settings
5.11 Setting control loops
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
0x29E1 | 0x31E1 - field: Field set value limitation
0x29E2 | 0x31E2 - DC link circuit voltage: Filter time
0x29E3 | 0x31E3 - motor: Actual voltage - filter time
0x29E4 | 0x31E4 - Voltage reserve range
Subindex 2: Field weakening controller: Reset time
Setting range (min. value | unit | max. value) Lenze setting
1.0 ms 240000.0 2000.0 ms
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 UNSIGNED_32
Setting range (min. value | unit | max. value) Lenze setting
5.00 % 100.00 100.00 %
 Write access  CINH  OSC  P  RX  TX Scaling: 1/100 UNSIGNED_16
Setting range (min. value | unit | max. value) Lenze setting
1.0 ms 1000.0 25.0 ms
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 UNSIGNED_16
Setting range (min. value | unit | max. value) Lenze setting
1.0 ms 1000.0 25.0 ms
 Write access  CINH  OSC  P  RX  TX Scaling: 1/10 UNSIGNED_16
From version 01.03
Voltage reserve range at the transition point to the field weakening
• Only relevant for servo control for asynchronous motor (selection "2" in 0x2C00
or 0x3400 for axis B).
Setting range (min. value | unit | max. value) Lenze setting
1%205%
 Write access  CINH  OSC  P  RX  TX UNSIGNED_8
